Boss GEB-7 7-Band Graphic Bass Equalizer
|
|
PRECISE TONAL CONTROL
The GEB-7 is a seven-band equalizer created specifically for the frequency range of the electric bass. Since the frequency range extends down to 50Hz, the GEB-7 is also great for adjusting depth and bottom end of an upright bass with pickups.
The GEB-7 is a seven-band equalizer created specifically for the frequency range of the electric bass. Since the frequency range extends down to 50Hz, the GEB-7 is also great for adjusting depth and bottom end of an upright bass with pickups.
Features:
- 50Hz to 10kHz frequency range specifically designed for bass
- Full range response, even for five- and six-string basses
- Can be used as a "boost" or "cut" pedal using the level control knob
- Great for eletric-acoustic bass applications
- AC adaptor or 9V battery operation
- BOSS five-year warranty
- Nominal Input Level: -20 dBu
- Input Impedance: 1 M ohm
- Nominal Output Level: -20 dBu
- Output Impedance: 1 k ohm
- Recommended Load Impedance: 10 k ohm or greater
- Bypass: Buffered bypass
- Controls
- Level Control knob
- Equalizer Control knob
- 50, 120, 400, 500, 800, 4.5 k, 10 kHz
- Pedal switch
- Indicator: CHECK indicator (Serves also as battery check indicator)
- Connectors
- INPUT jack: 1/4-inch phone type
- OUTPUT jack: 1/4-inch phone type DC IN jack
- Power Supply: Carbon-zinc battery (9 V, 6F22)
- Alkaline battery (9 V, 6LR61)
- AC adaptor (PSA series: sold separately)
- Current Draw: 16 mA
- Expected battery life under continuous use
- Carbon: Approx. 16.0 hours
- Alkaline: Approx. 28.5 hours
- *These figures will vary depending on the actual conditions of use.
- Accessories: Owner's Manual Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information") Carbon-zinc battery (9 V, 6F22) Option (sold separately): AC adaptor: PSA series
